BSS025
Technical Data
Machine | Type | Unit | BSS-025 |
Input Voltage | V | 110 / 220-240 | |
Welding Range - Band Saws / Band Knives | Metal Band Saws | mm | 6.0 x 0.6 - 20 x 0.8 |
Wood Cutting Band Saws | mm | 6.0 x 0.4 - 25 x 0.7 | |
Band Knives | mm | 6.0 x 0.4 - 20 x 0.7 | |
Welding Range - Steel Strip | S235JR (St37-2) | mm² | 20 |
X5CrNi18-10 (1.4301) | mm² | 15 | |
Clamping System | Upset Pressure | N | 50 |
Clamping Width | mm | 25 | |
Thickness Range | mm | 0.4-1.5 | |
Output Capacity (50% Duty Cycle) | KVA | 3 | |
Secondary Voltage Taps | steps | 4 | |
Dimensions & Weight | mm | 174×210×270 | |
Weight | kg | 18 |
Technical Data
Machine | Type | Unit | BSS-025 |
Input Voltage | V | 110 / 220-240 | |
Welding Range - Band Saws / Band Knives | Metal Band Saws | mm | 6.0 x 0.6 - 20 x 0.8 |
Wood Cutting Band Saws | mm | 6.0 x 0.4 - 25 x 0.7 | |
Band Knives | mm | 6.0 x 0.4 - 20 x 0.7 | |
Welding Range - Steel Strip | S235JR (St37-2) | mm² | 20 |
X5CrNi18-10 (1.4301) | mm² | 15 | |
Clamping System | Upset Pressure | N | 50 |
Clamping Width | mm | 25 | |
Thickness Range | mm | 0.4-1.5 | |
Output Capacity (50% Duty Cycle) | KVA | 3 | |
Secondary Voltage Taps | steps | 4 | |
Dimensions & Weight | mm | 174×210×270 | |
Weight | kg | 18 |
